GEFFEN HDBaseT twisted pair extender is a long-distance HD signal non compression and non delay transmitter integrated with HDBaseT. The equipment has excellent image processing capabilities and transmission capabilities, making the signal transmission more smooth and stable, It is a reliable and high-performance HDMI signal extension method. Support CEC function, RS232 two-way communication function and two-way IR control. In addition, it also supports two-way 12VPoC function, with power supply at either end.
GEFFEN HDBaseT twisted pair extender is a long-distance HD signal non compression and non delay transmitter integrated with HDBaseT. The equipment has excellent image processing capabilities and transmission capabilities, making the signal transmission more smooth and stable, It is a reliable and high-performance HDMI signal extension method. Support CEC function, RS232 two-way communication function and two-way IR control. In addition, it also supports two-way 12VPoC function, with power supply at either end.
characteristic
●HDMI signals are output from the receiving end,
●with a signal resolution of up to 4Kx2K.
●transmit high-definition uncompressed audio and video signals over a long distance through a single CAT5/CAT6 network cable
● can transmit up to 70/100 meters with a single network cable.
HDMI video and audio signals can be transmitted over a long distance through a single network cable, up to 70/100m.
Support full HD video signal, up to 1920* 1080@60Hz 、3840* 2160@30 。
It supports straight through EDID transmission function and adaptive display end EDID to meet more application scenarios.
It conforms to HDMI 1.3 standard and is compatible with HDMI 1.4.
Comply with HDCP 1.2 standard - high bandwidth digital content protection technology.
PoH (Power Over HDBaseT) power supply is supported. Connect a power adapter at either end of the transmitter or receiver to supply power to the other end through the network cable.
The network cable adopts the standard Ethernet IEEE-568B connection method, which is convenient for installation.
Built in automatic balance system, the picture is smooth, clear and stable.
Built in ESD static protection circuit, over-current protection circuit and anti reverse connection circuit protect the system safety in all directions.
Power supply voltage: DC12V.
Easy installation, plug and play, no need to install drivers.
|
Parameter |
Detailed Description |
|||
|
video |
Agreement |
HDMI1.3、HDMI 1.4，HDCP1.x、HDCP2.2 |
||
|
Interface bandwidth |
10.2Gbps |
|||
|
maximum resolution |
4K@60Hz/4:2:0 YCbCr, sYCC601, Adobe YCC-601 |
|||
|
Interface |
HDMI-A |
|||
|
impedance |
100Ω |
|||
|
maximum input/output distance |
TP-HD141 less than 5 meter TP-HD241 less than 15meter |
|||
|
network |
interface |
RJ45 interface |
||
|
cable |
Ethernet IEEE-568B standard connection |
|||
|
Maximum distance |
See "Transmission distance" table below |
|||
|
other |
power supply |
12V 1.5A |
||
|
Maximum power consumption |
MAX 10W |
|||
|
Operating ambient temperature |
0-50℃ |
|||
|
Working environment humidity |
5%~90% |
|||
|
Overall dimensions |
110x80x25mm |
|||
|
transmission distance |
||||
|
TP-HD141 |
||||
|
cable type |
length |
support video |
||
|
CAT5e/CAT6 |
60米 |
1080p@60Hz |
||
|
CAT6a/CAT7 |
70米 |
|||
|
CAT5e/CAT6 |
35米 |
HDMI 4K@30。HDMI 2.0 4K/60/4:2:0 YCbCr, sYCC601, Adobe YCC-601 |
||
|
CAT6a/CAT7 |
40米 |
|||
|
TP-HD241 |
||||
|
cable type |
length |
support video |
||
|
CAT5e/CAT6 |
100米 |
1080p@60Hz |
||
|
70米 |
HDMI 4K@30,HDMI 2.0 4K/60/4:2:0 YCbCr, sYCC601, Adobe YCC-601 |
|||
|
CAT6a/CAT7 |
100米 |
HDMI 4K@30, HDMI 2.0 4K/60/4:2:0 YCbCr, sYCC601, Adobe YCC-601 |
||
